LFXTAL026394BULK

Overview

The LFXTAL026394BULK is a quartz crystal oscillator manufactured by IQD Frequency Products, designed for high-speed clock generation in industrial and consumer electronics. It operates at a fundamental frequency of 20.0000 MHz with a load capacitance of 16 pF. The component utilizes surface mount technology (SMD) packaging. It supports an operating temperature range from -20°C to +70°C and complies with RoHS standards for lead-free construction.

Feature Summary

• High stability performance suitable for precise timing applications
• Surface mount design for automated assembly integration
• Lead-free construction compliant with environmental regulations

Applications

• Industrial electronic systems requiring stable clock signals
• Consumer electronics utilizing high-speed data processing
• General-purpose microcontroller clock sources

Procurement Notes

Verify the specific package dimensions and pin configuration against the official IQD datasheet prior to PCB layout finalization. Confirm that the 16 pF load capacitance matches the target circuit's requirements to ensure accurate frequency operation. Ensure the selected variant meets the required -20°C to +70°C operating temperature range for the intended application environment.

Selection Notes

Select this component when a 20 MHz surface-mount crystal is required for cost-sensitive designs. Consider the 16 pF load capacitance compatibility with the host oscillator circuit. Evaluate the thermal performance within the specified -20°C to +70°C range against the operational conditions of the end product.

Part Context

This part belongs to the IQD Frequency Products portfolio of quartz crystals and oscillators. The manufacturer specializes in providing timing solutions including TCXOs, VCXOs, and OCXOs for global markets. The LFXTAL series represents standard crystal components used for basic frequency reference needs.

Replacement Considerations

Direct substitutes must match the 20 MHz frequency, 16 pF load capacitance, and SMD package type. Verify equivalent electrical parameters such as ESR and drive level before substitution.
