LFXTAL059082

Overview

The LFXTAL059082 is a quartz crystal resonator manufactured by IQD Frequency Products. It operates at a nominal frequency of 8 MHz with a load capacitance of 10 pF. The component features a frequency tolerance of ±20 ppm and a frequency stability of ±50 ppm. It utilizes an SMD/SMT mounting style within a 7 mm x 5 mm package. The equivalent series resistance (ESR) is specified at 80 Ohms. The device supports surface mount installation techniques for integration into electronic circuits.

Feature Summary

• Provides stable 8 MHz timing reference
• Supports surface mount technology integration
• Ensures precise frequency control via low tolerance

Applications

• Microcontroller clock sources
• Communication interface timing
• Digital signal processing systems

Procurement Notes

Verify the specific package dimensions and pin configuration against the official datasheet before PCB layout finalization. Confirm that the load capacitance requirements of the target circuit match the 10 pF specification to ensure accurate oscillation. Check RoHS compliance status if environmental regulations apply to the end product. Ensure the operating temperature range aligns with the intended application environment.

Selection Notes

Select this component when a compact 8 MHz timing source is required for space-constrained designs. The 7 mm x 5mm footprint offers a balance between size and performance. Consider the 80 Ohm ESR value when designing the oscillator circuit to guarantee reliable startup. Evaluate the ±20 ppm tolerance against the system's frequency accuracy requirements.

Part Context

This part belongs to the IQD Frequency Products quartz crystal lineup, designed for general-purpose timing applications. It complements other components in their portfolio by offering standard frequencies in surface-mount packages. The LFXTAL series focuses on providing reliable resonators for consumer and industrial electronics requiring precise clock signals.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
