LFXTAL060055

Overview

The LFXTAL060055 is a surface-mount quartz crystal manufactured by IQD Frequency Products. It operates at a fundamental frequency of 24 MHz with a load capacitance of 18 pF. The component exhibits a frequency tolerance of ±20 ppm and an equivalent series resistance (ESR) of 40 Ohms. Designed for the HC-49/U package, it supports base harmonic operation within a temperature range of -40°C to +85°C.

Feature Summary

• Provides precise timing signals via fundamental resonance mode
• Supports surface-mount integration in compact electronic assemblies
• Maintains frequency stability across extended industrial temperature ranges

Applications

• Microcontroller clock circuits
• Communication interface synchronization
• Industrial control system timing references

Procurement Notes

Verify the specific ordering suffix required for your packaging preference, such as tape and reel or cut tape, when placing orders. Confirm that the HC-49/U footprint matches your PCB design constraints. Ensure the 18 pF load capacitance aligns with your circuit's oscillator requirements to maintain the specified ±20 ppm accuracy. Check RoHS compliance status if environmental regulations apply to your production line.

Selection Notes

Select this component when a 24 MHz reference is needed for space-constrained designs requiring surface-mount technology. The HC-49/U form factor offers a balance between performance and size compared to larger through-hole alternatives. Consider the 40 Ohm ESR value to ensure compatibility with your oscillator circuit's drive level specifications. Verify that the operating temperature range meets the environmental conditions of the final application.

Part Context

This part belongs to the standard quartz crystal lineup from IQD Frequency Products, a subsidiary of Würth Elektronik. The manufacturer specializes in frequency control solutions for global markets. The LFXTAL series typically covers various frequencies and packages, serving diverse sectors including consumer electronics and industrial automation. This specific model represents a common frequency point used in digital logic applications.

Replacement Considerations

Direct substitutes must match the 24 MHz frequency, 18 pF load capacitance, HC-49/U package, and ±20 ppm tolerance. Verify ESR compatibility and temperature range equivalence. Cross-reference with other manufacturers offering HC-49/U SMD crystals to ensure pinout and dimensional compatibility.
