LFXTAL078574BULK

Overview

The LFXTAL078574BULK is a through-hole quartz crystal manufactured by IQD Frequency Products. It operates at a nominal frequency of 24.0 MHz with a load capacitance of 20 pF. The component supports a frequency tolerance of 30 PPM and a stability of 50 PPM. It functions within an extended temperature range from -10°C to +70°C. The device utilizes a fundamental mode resonance with an equivalent series resistance of 20 Ohms. This part is supplied in bulk packaging for standard surface mount or through-hole integration.

Feature Summary

• Provides stable timing signals via fundamental mode quartz resonance
• Designed for operation across an extended industrial temperature range
• Supports standard load capacitance requirements for oscillator circuits

Applications

• Industrial control systems requiring precise timing references
• Consumer electronics utilizing 24 MHz clock sources
• Communication equipment needing stable frequency generation

Procurement Notes

Verify the specific package type and lead time directly with authorized distributors, as availability may vary. Confirm that the through-hole configuration matches your PCB design requirements. Ensure the operating temperature range meets your application's environmental specifications before finalizing procurement decisions.

Selection Notes

Select this component when a 24 MHz fundamental crystal is required for through-hole assembly. Consider the 20 pF load capacitance compatibility with your oscillator circuit design. Evaluate the -10°C to +70°C temperature range against your operational environment constraints to ensure reliable performance.

Part Context

This part belongs to the IQD Frequency Products quartz crystal portfolio, which includes various commercial and industrial grade timing solutions. IQD provides components ranging from simple watch crystals to high-performance oscillators. The LFXTAL series specifically addresses applications requiring reliable fundamental mode resonance in standard packages.

FAQ

What is the maximum operating temperature for this crystal?

The maximum operating temperature is +70°C.

Is this component available in a surface mount package?

No, this specific part number indicates a through-hole configuration.
