LFXTAL082087REEL

Overview

The LFXTAL082087REEL is a quartz crystal manufactured by IQD Frequency Products, operating at a fundamental frequency of 40 MHz. It features a load capacitance of 10 pF and offers a frequency tolerance of ±10 ppm with a stability of ±10 ppm. The component utilizes an SMD package measuring 2.50 mm in length and 2.00 mm in width, with a maximum height of 0.80 mm. It supports surface mount installation and operates within a temperature range of -40°C to +85°C.

Feature Summary

• Provides precise 40 MHz clock signal generation for digital circuits
• Ensures high frequency stability with ±10 ppm tolerance
• Designed for compact surface-mount PCB layouts

Applications

• Microcontroller clock sources
• Communication interface timing
• Digital logic circuit synchronization

Procurement Notes

Verify the specific ordering suffix against the manufacturer's current documentation to ensure compatibility with required packaging formats such as tape and reel or cut tape. Confirm that the selected variant meets all environmental and electrical specifications for the intended application before finalizing procurement orders.

Selection Notes

Select this component when a 40 MHz reference is required with tight frequency tolerance. Ensure the design accommodates the specified 10 pF load capacitance and verify that the operating temperature range aligns with system requirements. Check footprint dimensions against the PCB layout constraints.

Part Context

This part belongs to the IQD Frequency Products quartz crystal portfolio, designed for general-purpose timing applications. It represents a standard surface-mount solution offering reliable performance for embedded systems requiring stable clock references without the complexity of active oscillators.

Replacement Considerations

Cross-reference with other 40 MHz crystals from IQD or compatible manufacturers ensuring identical pinout, load capacitance, and dimensional constraints. Verify equivalent frequency stability and temperature range specifications before substitution.
