LFXTAL083388

Overview

The LFXTAL083388 is a surface-mount quartz crystal resonator manufactured by IQD Frequency Products. It operates at a fundamental frequency of 12 MHz with a load capacitance of 12 pF. The component features a frequency tolerance of ±20 ppm and a frequency stability of 30 ppm. It utilizes a 4-SMD, No Lead package measuring 3.2 mm in length and 2.5 mm in width. The equivalent series resistance (ESR) is specified at 120 ohms, with an excitation level of 100 uW. The device supports a wide operating temperature range from -40°C to +105°C.

Feature Summary

• Provides stable 12 MHz timing signals for digital circuits
• Supports high-temperature operation up to 105°C
• Utilizes compact surface-mount packaging for automated assembly

Applications

• Microcontroller clock sources
• Communication interface timing
• Industrial control systems

Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure correct packaging configuration. Confirm that the required frequency tolerance and stability meet the target circuit specifications. Check RoHS compliance status if environmental regulations apply to the final product assembly.

Selection Notes

Select this component when a 12 MHz reference is required in a space-constrained design. Ensure the application environment remains within the -40°C to +105°C operational limits. Verify that the 12 pF load capacitance matches the oscillator circuit requirements to maintain accurate frequency performance.

Part Context

This part belongs to the IQD Frequency Products quartz crystal lineup. It represents a standard fundamental mode resonator designed for general-purpose timing applications. The product line emphasizes reliability across various industrial and commercial sectors.

Replacement Considerations

Consult official substitution guides for compatible alternatives. Cross-reference pinout and electrical parameters before integrating any substitute components.
