LG T770-L1M2-1-Z

LED Indication - Discrete Overview

The LG T770-L1M2-1-Z is a green discrete LED from the TOPLED series, manufactured by ams OSRAM. It features a 570nm peak wavelength and emits light through a clear, round lens with a flat top design. The component operates at a typical forward voltage of 2V and has a millicandela rating of 19.6mcd. It utilizes a 2-SMD Z-Bend (gull wing) package configuration for surface mount installation.

LED Indication - Discrete Feature Summary

• Emits green light at a 570nm peak wavelength
• Features a clear round lens with a flat top style
• Utilizes a 2-SMD Z-Bend gull wing package

LED Indication - Discrete Applications

• Fiber optic communication systems
• Display technologies
• Medical imaging equipment
• Industrial automation controls

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix to ensure the correct lens style and packaging variant are selected. Confirm that the Z-Bend gull wing footprint matches the target PCB layout requirements before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component when a standard green indicator with a 570nm peak is required. Ensure the 2V forward voltage aligns with the system's drive circuit capabilities and verify compatibility with the 2-SMD Z-Bend mounting process.

LED Indication - Discrete Part Context

This part belongs to the TOPLED discrete LED family produced by ams OSRAM. It is designed for general indication purposes within electronic assemblies, offering a reliable green light source in a compact surface-mount form factor suitable for various consumer and industrial devices.

LED Indication - Discrete Replacement Considerations

Cross-reference with other green LEDs in the 2-plcc or 2-smd gull wing packages from the same manufacturer series to ensure mechanical and electrical compatibility if direct substitution is necessary.
