LLP.2500.X.A.30

Overview

The LLP.2500.X.A.30 is an LTCC low-pass filter designed for a center frequency of 2450 MHz with a bandwidth of 100 MHz. It operates at 50 ohms impedance and features surface mount termination in a 0603 package (1.60mm x 0.80mm). Key electrical specifications include 0.5 dB ripple and 0.42 dB insertion loss. The component functions within a temperature range of -40°C to +85°C.

Feature Summary

• LTCC construction enables high-density PCB layout and excellent solderability
• Compact 0603 footprint facilitates easy visual inspection capability

Applications

• RF signal filtering in wireless communication systems
• Low-pass filtering for 2.45 GHz ISM band applications
• Signal conditioning in compact electronic modules

Procurement Notes

Verify the specific suffix 'A' against the manufacturer's current datasheet to confirm exact electrical tolerances and packaging configuration. Ensure the ordering code matches the required tape and reel or cut tape format. Cross-reference the RoHS compliance status with the latest regulatory documentation before finalizing procurement orders.

Selection Notes

Select this component when a low-profile, surface-mount solution is required for 2.45 GHz applications. The 0603 size suits space-constrained designs. Verify that the 100 MHz bandwidth and 0.42 dB insertion loss meet the system's signal integrity requirements. Confirm compatibility with standard SMT reflow processes.

Part Context

This part belongs to Taoglas's LLP series of LTCC filters. These components are engineered for RF signal conditioning, offering a balance between performance and physical size. The series supports various frequencies, with this specific model targeting the 2.45 GHz band for industrial, scientific, and medical use cases.

Replacement Considerations

Consult official substitution guides for equivalent LTCC low-pass filters. Verify pinout compatibility and dimensional constraints before replacing. Ensure alternative parts match the 50-ohm impedance and operating temperature range.
