LLTH560CEN

Overview

The LLTH560CEN is a NEMA 4X polycarbonate enclosure manufactured by Hoffman Enclosures, Inc. It features a transparent window for internal visibility and includes a mounting plate. The unit measures 21.75 inches in height, 13.5 inches in width, and 8.5 inches in depth. It provides IP66 protection against dust and water ingress while maintaining UL Type 4X compliance for harsh environments.

Feature Summary

• Transparent polycarbonate construction allows visual inspection of internal components without opening the door.
• NEMA 4X rating ensures resistance to corrosion, dust, and water jets in demanding industrial settings.
• Integrated mounting plate facilitates secure installation of electrical or electronic equipment.

Applications

• Industrial control panels requiring visual monitoring
• Outdoor electrical installations exposed to moisture
• Chemical processing environments with corrosive agents

Procurement Notes

Verify that the specific order matches the LLTH560CEN designation to ensure correct dimensions and material properties. Confirm that the required mounting hardware is included or sourced separately. Check for any regional certification requirements such as UL or CE marking before finalizing procurement.

Selection Notes

Select this model when visual access to internal components is necessary alongside high environmental protection. Ensure the internal space accommodates the planned equipment layout on the provided mounting plate. Consider the weight limitations of the mounting surface given the polycarbonate construction.

Part Context

This component belongs to the Hoffman LLTH series of NEMA 4X enclosures. These units are designed for applications where standard metal enclosures are unsuitable due to corrosion concerns or the need for transparency. The series offers various sizes to accommodate different equipment footprints.

Replacement Considerations

Consult official Hoffman Enclosures documentation for direct cross-references. Verify dimensional compatibility and mounting hole patterns if substituting with other brands. Ensure the replacement maintains the same IP66/NEMA 4X rating and material specifications.
