LM336-2.5 MDC

$0.45

Description：IC VREF SHUNT 2.5V DIE
Series：-
Mfr：Texas Instruments
Package：Tray

SKU:22b95942a496 Category: Voltage Reference Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC VREF SHUNT 2.5V DIE
Series：-
Mfr：Texas Instruments
Package：Tray
Output Type：Fixed
Voltage - Output (Min/Fixed)：2.49V
Voltage - Output (Max)：-
Current - Output：20 mA
Operating Temperature：0°C ~ 70°C (TA)
Mounting Type：Surface Mount
Package / Case：Die
Supplier Device Package：Die
Grade：-
Qualification：-

Download product information

LM336-2.5 MDC

Overview

The LM336-2.5 MDC is a two-terminal integrated reference circuit manufactured by Texas Instruments, designed to provide a stable 2.5 V output voltage. It operates within a temperature range of 0°C to +70°C and features an initial accuracy of ±4%. The device exhibits a temperature coefficient of 20 PPM/°C and supports a maximum shunt current of 10 mA. Packaged in a TO-92-3 through-hole configuration, it functions as a precision shunt voltage reference suitable for low-voltage applications requiring reliable DC reference levels.

Feature Summary

Provides a fixed 2.5 V reference voltage via a two-terminal architecture
Operates with a wide current range from 400 μA to 10 mA
Maintains stability across the commercial temperature range of 0°C to +70°C

Applications

Digital voltmeters
Power supplies
Operational-amplifier circuitry

Procurement Notes

Verify the specific suffix 'MDC' against the official Texas Instruments datasheet to confirm package type and temperature grade. Ensure the ordering part number matches the required tolerance and operating range specifications before procurement. Cross-reference with authorized distributors to validate component authenticity and supply chain integrity.

Selection Notes

Select this component when a low-cost, two-terminal shunt reference is required for 2.5 V applications. Consider the ±4% initial accuracy and 20 PPM/°C temperature coefficient for circuit design margins. The TO-92 package is suitable for through-hole mounting where space constraints are minimal compared to surface-mount alternatives.

Part Context

The LM336 series includes variants such as LM136, LM236, and LM336, differentiated primarily by temperature ranges and manufacturing processes. The LM336-2.5 specifically targets commercial applications with a 0°C to +70°C operating range. This family serves as a fundamental building block for precision analog circuits requiring a stable voltage reference without complex external biasing networks.
