LM73606RNPT

$6.04

Description：IC REG BUCK ADJ 6A 30WQFN
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:543d63496dcf Category: Voltage Regulators - DC DC Switching Regulators Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LM73606RNPT is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Texas Instruments. Its product description is IC REG BUCK ADJ 6A 30WQFN. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for LM73606RNPT

Description：IC REG BUCK ADJ 6A 30WQFN
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Output Type：Adjustable
Number of Outputs：1
Voltage - Input (Min)：3.5V
Voltage - Input (Max)：36V
Voltage - Output (Min/Fixed)：1V
Voltage - Output (Max)：34.2V
Current - Output：6A
Frequency - Switching：350kHz ~ 2.2MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount, Wettable Flank
Package / Case：30-WFQFN Exposed Pad
Supplier Device Package：30-WQFN (6x4)
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for LM73606RNPT

LM73606RNPT

Voltage Regulators - DC DC Switching Regulators Overview

The LM73606RNPT is a synchronous step-down voltage converter manufactured by Texas Instruments. It operates with an input voltage range of 3.5 V to 36 V and delivers up to 6 A of output current. The device features adjustable output voltages from 1 V to 34.2 V. It supports switching frequencies between 350 kHz and 2.2 MHz and maintains a low quiescent current of 600 nA. The component is housed in a 30-WQFN package and functions within a temperature range of -40°C to +125°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Integrated synchronous rectification for high efficiency
Adjustable switching frequency for design flexibility
Low standby power consumption via shutdown mode

Voltage Regulators - DC DC Switching Regulators Applications

Industrial point-of-load regulation
Consumer electronics power distribution
Embedded system voltage conversion

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific suffix RNPT against official datasheets to confirm the WQFN-30 package and tape-and-reel delivery format. Ensure compatibility with moisture sensitivity level requirements during assembly. Cross-reference the manufacturer part number directly with Texas Instruments documentation to validate authenticity and revision status before procurement.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a single-output buck converter is required for inputs up to 36 V. It is suitable for designs needing up to 6 A continuous current with adjustable output settings. Consider the thermal performance of the exposed pad WQFN package for heat dissipation needs in compact layouts.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the LM73606 series of synchronous step-down converters. It shares architectural similarities with the LM73605, which offers 5 A output capability. Both devices utilize the same control topology and packaging options, differing primarily in maximum current handling specifications.
