LM76002QRNPRQ1

$2.24

Description：IC REG BUCK ADJ 2.5A 30WQFN
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR)

SKU:3efc0ae58a10 Category: Voltage Regulators - DC DC Switching Regulators Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LM76002QRNPRQ1 is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Texas Instruments. Its product description is IC REG BUCK ADJ 2.5A 30WQFN. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for LM76002QRNPRQ1

Description：IC REG BUCK ADJ 2.5A 30WQFN
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR)
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Output Type：Adjustable
Number of Outputs：1
Voltage - Input (Min)：3.5V
Voltage - Input (Max)：60V
Voltage - Output (Min/Fixed)：1V
Voltage - Output (Max)：57V
Current - Output：2.5A
Frequency - Switching：300kHz ~ 2.2MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount, Wettable Flank
Package / Case：30-WFQFN Exposed Pad
Supplier Device Package：30-WQFN (6x4)
Grade：Automotive
Qualification：AEC-Q100

Voltage Regulators - DC DC Switching Regulators datasheet and documents for LM76002QRNPRQ1

LM76002QRNPRQ1

Voltage Regulators - DC DC Switching Regulators Overview

The LM76002QRNPRQ1 is an automotive-grade synchronous step-down voltage converter from Texas Instruments. It supports an input voltage range of 3.5 V to 60 V and delivers a maximum output current of 2.5 A. The adjustable output voltage spans from 1 V to 57 V. The device operates with a switching frequency between 300 kHz and 2.2 MHz. It functions within a junction temperature range of -40°C to 150°C and utilizes a WQFN-30 package.

Voltage Regulators - DC DC Switching Regulators Feature Summary

AEC-Q100 qualified for automotive applications
Integrated synchronous rectification for high efficiency
Supports forced PWM mode and frequency synchronization
Includes overcurrent protection and power good indication

Voltage Regulators - DC DC Switching Regulators Applications

Automotive infotainment systems
Telematics control units
Body electronics modules
Industrial DC-DC conversion

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the suffix 'Q1' confirms AEC-Q100 qualification and extended temperature ratings. Confirm the 'RPR' suffix indicates reel packaging. Ensure the component matches the specific thermal and electrical requirements for automotive environments before procurement.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a wide input voltage range up to 60 V is required in an automotive setting. It is suitable for designs needing 2.5 A output current with adjustable voltage settings. Consider the WQFN-30 package for space-constrained PCB layouts requiring wettable flanks.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the LM76002 family, which includes standard industrial variants like the LM76002RNPR. The LM76002QRNPRQ1 is distinguished by its automotive qualification (AEC-Q100) and higher maximum junction temperature rating compared to non-Q1 versions.
