LMW78_09-0.5R

LMW78_09-0.5R is listed in the DC DC Converters range at ChipApex. The manufacturer field lists GAPTEC Electronic. Its product description is DC-DC STEP DOWN REGULATORS. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for LMW78_09-0.5R

• Description：DC-DC STEP DOWN REGULATORS
• Series：LMW78_0.5R
• Mfr：GAPTEC Electronic
• Package：Tube
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：14V
• Voltage - Input (Max)：90V
• Voltage - Output 1：9V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：500mA
• Power (Watts)：4.5 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：91%
• Mounting Type：Through Hole
• Package / Case：3-SIP Module
• Size / Dimension：0.45" L x 0.35" W x 0.69" H (11.5mm x 9.0mm x 17.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for LMW78_09-0.5R
