LN1371SGTRP

Description：LED GREEN DIFFUSED S-GW SMD
Series：-
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR)

SKU:bbfc9dc772b4 Category: LED Indication - Discrete Brand: Panasonic Electronic Components

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LN1371SGTRP is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is LED GREEN DIFFUSED S-GW SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for LN1371SGTRP

Description：LED GREEN DIFFUSED S-GW SMD
Series：-
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR)
Color：Green
Configuration：Standard
Lens Color：Green
Lens Transparency：Diffused
Millicandela Rating：2mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.70mm x 1.25mm
Voltage - Forward (Vf) (Typ)：1.9V
Current - Test：5mA
Viewing Angle：-
Mounting Type：Surface Mount
Wavelength - Dominant：-
Wavelength - Peak：565nm
Features：-
Package / Case：2-SMD, Gull Wing
Supplier Device Package：S-GW Type LED
Size / Dimension：1.70mm L x 1.25mm W
Height (Max)：1.10mm
Grade：-
Qualification：-
