LNA-40-08001800-23-15P

Overview

The LNA-40-08001800-23-15P is a low-noise amplifier module manufactured by L3 Narda-MITEQ, designed for signal conditioning in the 8 GHz to 18 GHz frequency range. It provides a nominal gain of 40 dB with a noise figure of 2.3 dB and a P1dB output power of 15 dBm. The device operates on a 15 V DC supply and functions within an ambient temperature range of -55°C to +85°C. This component is housed in a modular package suitable for integration into RF systems requiring high linearity and low noise performance.

Feature Summary

• Provides high gain amplification within the 8 GHz to 18 GHz operational bandwidth
• Achieves low noise figure specifications for sensitive signal detection
• Operates reliably across extended industrial temperature ranges

Applications

• VSAT communication systems
• RF instrumentation
• Sensor signal conditioning

Procurement Notes

Verify the manufacturer part number against official L3 Narda-MITEQ documentation to ensure authenticity. Confirm that the specific suffix matches the required electrical parameters, particularly the 2.3 dB noise figure and 15 dBm P1dB rating. Check for RoHS compliance status if environmental regulations apply to your deployment. Ensure the supplier provides valid traceability documents for this signal conditioning component.

Selection Notes

Select this model when a 40 dB gain is required alongside a 2.3 dB noise figure in the 8–18 GHz band. Consider the 15 dBm P1dB limit for linearity requirements. Evaluate the 15 V DC power requirement and current consumption against available system resources. Compare thermal management needs against the -55°C to +85°C operating range for your specific environment.

Part Context

This component belongs to the LNA series of low-noise amplifiers from L3 Narda-MITEQ. These modules are engineered for RF applications demanding precise signal integrity. The product line typically includes various configurations optimized for different frequency bands and gain levels, serving as critical front-end components in radar, communications, and test equipment.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Verify compatibility with existing circuit designs before considering alternative models from other manufacturers.
