LNJ436W82RA

Description：LED AMBER ESS TYPE LED SMD
Series：-
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR)

SKU:f2230d6fee32 Category: LED Indication - Discrete Brand: Panasonic Electronic Components

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LNJ436W82RA is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is LED AMBER ESS TYPE LED SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for LNJ436W82RA

Description：LED AMBER ESS TYPE LED SMD
Series：-
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR)
Color：Amber
Configuration：Standard
Lens Color：-
Lens Transparency：-
Millicandela Rating：25mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.60mm x 0.80mm
Voltage - Forward (Vf) (Typ)：1.95V
Current - Test：5mA
Viewing Angle：-
Mounting Type：Surface Mount
Wavelength - Dominant：590nm
Wavelength - Peak：595nm
Features：-
Package / Case：0603 (1608 Metric)
Supplier Device Package：-
Size / Dimension：1.60mm L x 0.80mm W
Height (Max)：0.25mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for LNJ436W82RA

LNJ436W82RA

LED Indication - Discrete Overview

The LNJ436W82RA is a single-color amber LED from the Panasonic LN series, designed for surface-mount technology in a 0805 (2012 metric) package. It features a rectangular lens measuring 0.8 mm x 1.6 mm with a height of 0.4 mm. The component emits light at a wavelength of 605 nm and provides an optical intensity of 25 mcd when driven at a forward current of 5 mA. The typical forward voltage is 1.95 V, with a power rating of 55 mW. It operates within a temperature range of -30°C to +85°C and includes moisture sensitivity protection.

LED Indication - Discrete Feature Summary

Surface-mount design suitable for automated assembly processes
Rectangular lens geometry for directional light emission
Amber color output optimized for visual indication

LED Indication - Discrete Applications

Status indication on electronic circuit boards
Visual signaling in consumer electronics devices
Control panel indicator lights

LED Indication - Discrete Procurement Notes

Verify the exact package dimensions and spectral characteristics against the official Panasonic datasheet before integration. Confirm that the amber wavelength aligns with visibility requirements for the target application environment. Ensure handling procedures account for moisture sensitivity levels specified in the manufacturing documentation to prevent soldering defects during reflow processes.

LED Indication - Discrete Selection Notes

Select this component for applications requiring a compact amber indicator with standard SMD footprint compatibility. Consider the 0805 size constraint and the specific luminous intensity requirements for visibility under ambient lighting conditions. Evaluate the thermal management capabilities relative to the maximum operating temperature limits defined in the technical specifications.

LED Indication - Discrete Part Context

This part belongs to the Panasonic LN series of single-color LEDs, which are engineered for reliable performance in various electronic assemblies. The series offers standardized dimensions and electrical characteristics to facilitate consistent design implementation across different product lines manufactured by Panasonic Electronic Components.
