LNJ461C34RA

Description：LED AMBER CLEAR 2SMD
Series：-
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e1213cd5f77d Category: LED Indication - Discrete Brand: Panasonic Electronic Components

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LNJ461C34RA is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is LED AMBER CLEAR 2SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for LNJ461C34RA

Description：LED AMBER CLEAR 2SMD
Series：-
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Amber
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：18mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.70mm x 1.25mm
Voltage - Forward (Vf) (Typ)：2V
Current - Test：10mA
Viewing Angle：-
Mounting Type：Surface Mount
Wavelength - Dominant：-
Wavelength - Peak：595nm
Features：-
Package / Case：2-SMD, Gull Wing
Supplier Device Package：2-SMD
Size / Dimension：3.00mm L x 2.20mm W
Height (Max)：1.80mm

LED Indication - Discrete datasheet and documents for LNJ461C34RA

LNJ461C34RA

LED Indication - Discrete Overview

The Panasonic LNJ461C34RA is an amber-colored, clear lens surface-mount LED indicator. It features a standard configuration with a rectangular lens style and flat top design. The component measures 3.00mm in length, 2.20mm in width, and has a maximum height of 1.80mm. It utilizes a 2-SMD gull-wing package with a lens size of 1.70mm x 1.25mm. Key electrical parameters include a typical forward voltage of 2V at a test current of 10mA, a peak wavelength of 595nm, and a luminous intensity of 18mcd.

LED Indication - Discrete Feature Summary

Amber light emission with a clear, transparent lens for high visibility
Standard surface-mount construction with gull-wing leads for reliable PCB attachment
Rectangular lens profile with a flat top to optimize optical distribution

LED Indication - Discrete Applications

General status indication on electronic control panels
Power state signaling in consumer appliances
Visual feedback components in industrial instrumentation

LED Indication - Discrete Procurement Notes

Verify the obsolete status of this component before integration into new designs. Confirm that existing inventory or last-time-buy options meet project timelines. Ensure replacement strategies are defined if supply chain continuity is required for long-term production runs.

LED Indication - Discrete Selection Notes

Choose this part when a specific amber color and low-profile SMD form factor are required. Verify that the 2V forward voltage aligns with the driving circuit capabilities. Consider the 18mcd intensity sufficient for the intended viewing distance and ambient lighting conditions.

LED Indication - Discrete Part Context

This component belongs to the LNJ461 series of discrete LED indicators manufactured by Panasonic Industry. These devices are designed for general-purpose visual signaling applications where compact dimensions and standard mounting configurations are preferred over specialized optical or high-power requirements.
