LP0603N5200ANTR

Overview

The LP0603N5200ANTR is a low-pass RF filter manufactured by KYOCERA AVX, designed for signal conditioning applications. It features a center frequency of 5.2 GHz and a bandwidth of 300 MHz. The component operates within a 50 Ohm impedance system and utilizes SMD/SMT termination types. It is housed in a compact 0603 (1608 metric) package with dimensions of 1.60mm x 0.84mm and a maximum height of 0.70mm. The device supports a wide operating temperature range from -40°C to +85°C and complies with RoHS3 standards.

Feature Summary

• Provides low-pass filtering characteristics for RF signal conditioning
• Designed for surface mount board mounting in compact spaces
• Operates reliably across extended industrial temperature ranges

Applications

• RF signal path filtering in wireless communication modules
• Signal conditioning in high-frequency electronic circuits
• Integration into compact RF front-end assemblies

Procurement Notes

Verify the specific datasheet version for precise attenuation curves and insertion loss values before finalizing design integration. Confirm that the 0603 footprint matches the target PCB layout constraints. Ensure compatibility with standard reflow soldering profiles for SMD components. Check for any recent engineering change notices regarding material composition or packaging updates.

Selection Notes

Select this component when a 5.2 GHz center frequency with 300 MHz bandwidth is required in a 0603 form factor. Consider the LP0402N5200ANTR if a smaller 0402 package is necessary for space-constrained designs. Evaluate the LP0603N5500ANTR if a higher center frequency of 5.5 GHz better suits the application requirements. Ensure the 50 Ohm impedance matches the system design.

Part Context

This part belongs to the LP series of lead-free LGA type low-pass filters from KYOCERA AVX. These components are engineered for RF and microwave applications requiring stable performance in small packages. The series offers various center frequencies and bandwidth options to support diverse signal processing needs in modern electronic devices.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
