LP0AA0145A700

Overview

The LP0AA0145A700 is a surface-mount low-pass filter manufactured by KYOCERA AVX, belonging to the MLO series. It operates at a cutoff frequency of 145 MHz with a nominal impedance of 50 Ohms. The component utilizes an SMD/SMT termination type and is housed in a 2616 (6640 metric) package. It supports board mounting and functions within a temperature range of -55°C to +85°C.

Feature Summary

• Provides signal conditioning via low-pass filtering characteristics
• Designed for surface-mount technology integration
• Constructed using ceramic materials for RF applications

Applications

• RF signal processing circuits
• Wireless communication systems
• Signal conditioning modules

Procurement Notes

Verify current availability status directly with authorized distributors or the manufacturer, as supply levels fluctuate. Confirm RoHS compliance details and specific datasheet revisions prior to finalizing procurement orders to ensure alignment with project requirements and regulatory standards.

Selection Notes

Select this component when a 145 MHz low-pass characteristic is required in a compact 2616 footprint. Ensure the design accommodates the specified 50 Ohm impedance and operating temperature range. Verify that the surface-mount package aligns with the PCB layout and assembly capabilities.

Part Context

This part belongs to the KYOCERA AVX MLO series of signal conditioning components. These filters are engineered for radio frequency applications requiring precise attenuation of higher frequencies while passing lower frequency signals. The series offers various cutoff frequencies and package sizes to suit different circuit density needs.

Replacement Considerations

Consult official substitution guides for compatible alternatives within the MLO series or equivalent high-pass/low-pass filters from other manufacturers. Verify matching electrical parameters such as cutoff frequency, impedance, and insertion loss before considering any cross-reference.
