LP0AA0153A700

Overview

The KYOCERA AVX LP0AA0153A700 is a surface-mount low-pass filter designed for signal conditioning applications. It operates at a cutoff frequency of 153 MHz with a nominal impedance of 50 Ohms. The component utilizes an SMD/SMT termination type and is housed in a compact 2616 (6640 metric) package, measuring approximately 6.58mm x 3.98mm with a maximum height of 0.56mm. It functions within a temperature range of -55°C to +85°C and belongs to the MLO LP series.

Feature Summary

• Provides low-pass filtering characteristics for RF signal conditioning
• Designed for board mounting using surface mount technology
• Constructed for operation in standard industrial temperature ranges

Applications

• RF signal path filtering
• Base station equipment
• Wireless communication modules

Procurement Notes

Verify current availability status directly with authorized distributors or the manufacturer, as supply levels may fluctuate. Confirm that the specified 2616 package dimensions and 50 Ohm impedance align with your PCB layout requirements. Ensure compatibility with your assembly processes regarding the surface mount termination style and operating temperature specifications before finalizing procurement orders.

Selection Notes

Select this component when a 153 MHz cutoff frequency is required for low-pass filtering in 50 Ohm systems. The 2616 package size offers a balance between performance and board space efficiency. Consider the -55°C to +85°C operating range to ensure reliability under expected environmental conditions. Verify insertion loss specifications if detailed attenuation data is critical for your specific circuit design.

Part Context

This part belongs to the KYOCERA AVX MLO LP series of low-pass filters. These components are engineered for high-performance signal conditioning in RF applications. The series typically features robust construction suitable for demanding electronic environments. The LP0AA0153A700 specifically targets applications requiring precise filtering at the 153 MHz frequency point.

Replacement Considerations

Consult official substitution guides for compatible alternatives within the MLO LP series. Verify that any substitute maintains identical 50 Ohm impedance, 2616 package dimensions, and 153 MHz cutoff frequency. Ensure thermal and electrical specifications match original requirements to prevent circuit performance degradation.
