LP0AA0316A700

Overview

The LP0AA0316A700 is a surface-mount low-pass filter from the KYOCERA AVX MLO LP series, designed for signal conditioning applications. It operates at a cutoff frequency of 316 MHz with a 50 Ohm impedance. The component utilizes SMD/SMT termination and is housed in a compact 16ULGA (2616 metric) package. It features an insertion loss of 0.8 dB and supports a wide operating temperature range from -55°C to +85°C. The device is RoHS compliant and intended for board mount integration.

Feature Summary

• Provides low-pass filtering for signal conditioning within RF circuits
• Utilizes a compact 16ULGA surface-mount package for space-constrained designs
• Operates reliably across a wide industrial temperature range

Applications

• RF signal path filtering
• Signal conditioning modules
• Wireless communication equipment

Procurement Notes

Verify current availability status as this item may be subject to factory special order requirements. Confirm specific datasheet revisions and compliance documentation directly with the manufacturer or authorized distributors before finalizing procurement plans. Ensure ordering quantities align with available packaging formats.

Selection Notes

Select this component when a 316 MHz cutoff frequency and 50 Ohm system impedance are required. The 16ULGA package size suits high-density PCB layouts. Verify that the 0.8 dB insertion loss meets system budget constraints and that the -55°C to +85°C temperature range covers operational environmental conditions.

Part Context

This part belongs to the MLO LP series of low-pass filters manufactured by KYOCERA AVX. These components are engineered for signal conditioning tasks requiring precise frequency control. The series offers various cutoff frequencies packaged in small form factors suitable for modern electronic assemblies.

Replacement Considerations

Consult official substitution guides for compatible alternatives within the MLO LP series or equivalent low-pass filters from other manufacturers. Ensure any substitute matches the 316 MHz cutoff, 50 Ohm impedance, and 16ULGA package dimensions.
