Product Detailed Parameters
- Description：RF FILTER LOWPASS 3.16GHZ 16ULGA
- Series：LP
- Mfr：KYOCERA AVX
- Package：Bulk
- Frequency：3.16GHz
- Bandwidth：-
- Filter Type：Low Pass
- Ripple：-
- Insertion Loss：-
- Mounting Type：Surface Mount
- Package / Case：16-ULGA
- Size / Dimension：0.259" L x 0.156" W (6.58mm x 3.98mm)
- Height (Max)：0.022" (0.56mm)
Download product information
Overview
The LP0AA3160A700 is a surface-mount low-pass filter from the KYOCERA AVX MLO LP series, designed for signal conditioning applications. It operates at a cutoff frequency of 3.16 GHz with a nominal impedance of 50 Ohms. The component utilizes an SMD/SMT termination type and is housed in a 2616 (6640 metric) package, measuring approximately 6.58mm by 3.98mm. It supports board mounting and functions within a temperature range of -55°C to +85°C.
Feature Summary
- Provides low-pass filtering characteristics for RF signal conditioning
- Designed for surface-mount technology integration
- Operates at a standard 50 Ohm system impedance
Applications
- RF signal path filtering
- Wireless communication systems
- Base station equipment
Procurement Notes
Verify current manufacturing status as this part may be discontinued or not recommended for new designs. Confirm availability through authorized distributors, as stock levels are limited. Check for updated datasheets to ensure compliance with current RoHS standards and environmental regulations before procurement.
Selection Notes
Select this component for applications requiring a 3.16 GHz cutoff frequency in a compact 2616 package. Ensure the design accommodates the specific thermal operating range of -55°C to +85°C. Verify that the 50 Ohm impedance matches the system requirements for optimal signal transmission and minimal reflection.
Part Context
This component belongs to the MLO LP series of low-pass filters manufactured by KYOCERA AVX. These filters are engineered for high-frequency signal processing tasks. The series offers various cutoff frequencies tailored for different RF applications, providing reliable performance in demanding electronic environments.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Due to potential discontinuation status, consult the manufacturer for alternative recommendations or equivalent components within the same series that meet the required electrical specifications.
