LP0AA4080A700

Overview

The LP0AA4080A700 is a surface-mount low-pass filter from the KYOCERA AVX MLO series, designed for signal conditioning applications. It operates at a cutoff frequency of 4.08 GHz with a nominal impedance of 50 Ohms. The component utilizes a 16ULGA (2616 metric) package and features SMD/SMT termination types for board mounting. It exhibits an insertion loss of 0.7 dB and functions within a temperature range of -55°C to +85°C.

Feature Summary

• Provides low-pass filtering characteristics for RF signal conditioning
• Utilizes a compact 16ULGA surface-mount package design
• Maintains a standard 50 Ohm system impedance

Applications

• RF front-end modules in wireless communication systems
• Signal conditioning in high-frequency electronic circuits
• Base station and infrastructure equipment filtering

Procurement Notes

Verify current availability status directly with the manufacturer or authorized distributors, as supply conditions may vary. Confirm RoHS compliance documentation and specific ordering suffixes if required for your manufacturing process. Ensure that the 16ULGA footprint matches your PCB layout specifications before finalizing procurement decisions.

Selection Notes

Select this component when a 4.08 GHz low-pass filter is required for 50 Ohm systems. The 16ULGA package size suits space-constrained designs. Verify that the operating temperature range of -55°C to +85°C meets environmental requirements. Compare insertion loss specifications against other MLO series variants if different cutoff frequencies are needed.

Part Context

This part belongs to the KYOCERA AVX MLO LP series of low-pass filters. These components are engineered for high-performance RF applications requiring precise frequency control. The series offers various cutoff frequencies while maintaining consistent package dimensions and impedance characteristics for standardized design integration.

Replacement Considerations

Consult official substitution guides for compatible parts within the MLO LP series. Verify that alternative components match the 4.08 GHz cutoff, 50 Ohm impedance, and 16ULGA package dimensions. Cross-reference datasheets to ensure equivalent insertion loss and thermal performance ratings.
