LP0AA6160A700

Overview

The LP0AA6160A700 is a low-pass filter from the KYOCERA AVX MLO LP series, designed for signal conditioning applications. It operates at a frequency of 6.16 GHz with a 50 Ohm impedance. The component utilizes SMD/SMT termination and is housed in a 2616 (6640 metric) package. It supports board mounting and functions within a temperature range of -55°C to +85°C. This device is classified under RF filters and belongs to the Low Pass Filters subcategory.

Feature Summary

• Provides low-pass filtering characteristics for radio frequency signal conditioning
• Designed for surface mount technology integration on printed circuit boards
• Operates within standard industrial temperature ranges for reliable performance

Applications

• RF signal path filtering in communication systems
• Harmonic suppression in microwave circuits
• Signal conditioning in high-frequency electronic devices

Procurement Notes

Verify current manufacturing status as this product may be obsolete or not recommended for new designs. Confirm availability through authorized distributors or direct manufacturer channels. Ensure compatibility with existing PCB layouts and soldering processes. Check for updated documentation regarding RoHS compliance and environmental specifications before procurement.

Selection Notes

Select this component for applications requiring precise low-pass filtering at 6.16 GHz. Consider the 2616 package size for space-constrained designs. Evaluate thermal management requirements given the operating temperature range. Compare insertion loss and impedance matching against system specifications to ensure optimal signal integrity in RF environments.

Part Context

This part belongs to the MLO LP series of low-pass filters manufactured by KYOCERA AVX. These components are engineered for high-frequency signal processing tasks. The series offers various cutoff frequencies and package options to suit different RF design needs. The LP0AA6160A700 specifically targets the 6.16 GHz frequency band for specialized filtering requirements.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify if alternative models within the MLO LP series meet similar electrical specifications. Consult manufacturer documentation for potential end-of-life notices or recommended upgrades.
