LP0BA0790A700

Overview

The LP0BA0790A700 is a surface-mount low-pass filter from the KYOCERA AVX MLO LP series, designed for signal conditioning applications. It operates at a center frequency of 790 MHz with a nominal impedance of 50 Ohms. The component utilizes an SMD/SMT termination type and is housed in a 3116 (7840 metric) package. It supports board mounting and functions within an ambient temperature range of -55 °C to +85 °C.

Feature Summary

• Provides low-pass filtering characteristics for RF signal conditioning
• Engineered for surface-mount technology integration
• Designed for operation in demanding thermal environments

Applications

• RF front-end modules requiring 790 MHz cutoff
• Wireless communication systems utilizing 50 Ohm impedance matching
• Signal integrity management in electronic assemblies

Procurement Notes

Verify current availability status directly with authorized distributors or the manufacturer, as lead times may vary significantly due to production scheduling constraints. Confirm RoHS compliance documentation and specific packaging quantities prior to order placement. Ensure that the selected part number matches the required frequency and package specifications for your design implementation.

Selection Notes

Select this component when a 790 MHz low-pass filter is required for 50 Ohm systems. The 3116 package size offers a compact footprint suitable for space-constrained PCB layouts. Consider the operating temperature range of -55 °C to +85 °C to ensure reliability under expected environmental conditions. Validate insertion loss and rejection characteristics against system requirements using official datasheets.

Part Context

This device belongs to the MLO LP series of low-pass filters manufactured by KYOCERA AVX. These components are categorized under signal conditioning products within the broader filters subcategory. The series is engineered for high-performance RF applications, providing reliable attenuation of unwanted frequencies while maintaining signal integrity in critical communication pathways.

Replacement Considerations

Consult official substitution guides for compatible alternatives within the MLO LP series. Verify that any substitute maintains identical 790 MHz center frequency, 50 Ohm impedance, and 3116 package dimensions. Cross-reference electrical performance curves to ensure equivalent filtering behavior without compromising system stability.
