LP3985IBL-2.6

Description：IC REG LINEAR 2.6V 150MA 5-DSBGA
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e1e69c7321db Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LP3985IBL-2.6 is listed in the Voltage Regulators - Linear, Low Drop Out (LDO) Regulators range at ChipApex. The manufacturer field lists Texas Instruments. Its product description is IC REG LINEAR 2.6V 150MA 5-DSBGA. Review the specifications below when checking this part for your BOM.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators specifications for LP3985IBL-2.6

Description：IC REG LINEAR 2.6V 150MA 5-DSBGA
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)
Output Configuration：Positive
Output Type：Fixed
Number of Regulators：1
Voltage - Input (Max)：6V
Voltage - Output (Min/Fixed)：2.6V
Voltage - Output (Max)：-
Voltage Dropout (Max)：0.1V @ 150mA
Current - Output：150mA
Current - Quiescent (Iq)：150 µA
Current - Supply (Max)：250 µA
PSRR：50dB ~ 40dB (1kHz ~ 10kHz)
Control Features：Enable
Protection Features：Over Current, Over Temperature, Short Circuit
Operating Temperature：-40°C ~ 125°C
Mounting Type：Surface Mount
Package / Case：5-WFBGA, DSBGA
Supplier Device Package：5-DSBGA (1.41x1.08)
Grade：-
Qualification：-

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators datasheet and documents for LP3985IBL-2.6

LP3985IBL-2.6

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The LP3985IBL-2.6 is a micropower, low-noise, ultra-low-dropout CMOS voltage regulator manufactured by Texas Instruments. It provides a fixed 2.6V output with a maximum current of 150mA from an input range of 2.5V to 6.0V. The device operates within a junction temperature range of -40°C to +125°C and features a typical quiescent current of 85µA. It achieves a power supply rejection ratio (PSRR) of 50dB at 1kHz and maintains stability with small ceramic or high-quality tantalum output capacitors.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

Logic-controlled enable pin for power management
Internal pre-charging circuit for fast turn-on time
Optional external bypass capacitor for noise reduction without slowing transient response
Thermal shutdown and short-circuit current limit protection

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

CDMA cellular handsets
Wideband CDMA cellular handsets
GSM cellular handsets
Portable information appliances

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific package variant against design requirements, as the LP3985 series includes SOT-23-5 and multiple micro SMD bump configurations. Confirm that the ordering suffix matches the intended physical footprint and bump dimensions. Ensure compatibility with RoHS compliance standards if required by the manufacturing process.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this component for space-constrained portable designs requiring minimal board area. Verify that the application utilizes X7R ceramic capacitors to maintain stability across the full operating temperature range. Consider the light sensitivity of the micro SMD package during assembly and ensure adequate PCB layout practices are followed.
