LP87565CRNFTQ1

$6.35

Description：IC REG BUCK ADJ 16A QUAD 26VQFN
Series：LP8756x-Q1
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:a67607023bdf Category: Voltage Regulators - DC DC Switching Regulators Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LP87565CRNFTQ1 is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Texas Instruments. Its product description is IC REG BUCK ADJ 16A QUAD 26VQFN. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for LP87565CRNFTQ1

Description：IC REG BUCK ADJ 16A QUAD 26VQFN
Series：LP8756x-Q1
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Output Type：Adjustable
Number of Outputs：4
Voltage - Input (Min)：2.8V
Voltage - Input (Max)：5.5V
Voltage - Output (Min/Fixed)：0.6V
Voltage - Output (Max)：3.36V
Current - Output：16A
Frequency - Switching：2MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 125°C (TA)
Mounting Type：Surface Mount, Wettable Flank
Package / Case：26-PowerVFQFN
Supplier Device Package：26-VQFN-HR (4.5x4)
Grade：Automotive
Qualification：AEC-Q100

Voltage Regulators - DC DC Switching Regulators datasheet and documents for LP87565CRNFTQ1

LP87565CRNFTQ1

Voltage Regulators - DC DC Switching Regulators Overview

The LP87565CRNFTQ1 is a Texas Instruments automotive-grade PMIC featuring two synchronous buck converters in a 26-pin VQFN-HR package. It supports an input voltage range of 2.8V to 5.5V with adjustable outputs from 0.6V to 3.36V. The device delivers up to 16A per channel and operates at a switching frequency of 2MHz. Qualified under AEC-Q100, it functions between -40°C and +125°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Dual-channel synchronous buck topology for efficient power conversion
Integrated switches supporting high current delivery
Adjustable output voltage configuration via external resistors
Surface-mount design with wettable flanks for enhanced inspection

Voltage Regulators - DC DC Switching Regulators Applications

Automotive infotainment system power distribution
Telematics control unit voltage regulation
ADAS sensor module power supply
Body control module DC-DC conversion

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the complete part number against official Texas Instruments documentation to ensure correct suffix alignment. Confirm that the specific variant matches the required pinout and thermal characteristics. Cross-reference the datasheet revision history to validate component specifications before integration into production designs.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when dual independent buck regulators are required within automotive constraints. The 2MHz switching frequency allows for smaller passive components compared to lower-frequency alternatives. Ensure the application load does not exceed the 16A per channel rating while maintaining adequate thermal dissipation through the exposed pad.

Voltage Regulators - DC DC Switching Regulators Part Context

This device belongs to the LP8756x-Q1 family of multi-phase power management ICs designed for automotive applications. It complements other Texas Instruments solutions by providing dual high-current channels in a compact footprint, suitable for systems requiring multiple regulated rails from a single input source.
