LPF04023600LTT

Overview

The LPF04023600LTT is a radio frequency low-pass filter manufactured by KYOCERA AVX. It operates with a center frequency of 4.242 GHz and features a bandwidth of 3.516 GHz. The component exhibits an insertion loss of 0.35 dB. It is housed in a compact 0402 (1005 metric) surface-mount package designed for PCB integration.

Feature Summary

• Provides low-pass filtering characteristics for RF signal processing
• Utilizes a compact 0402 surface-mount footprint for space-constrained designs

Applications

• RF signal conditioning circuits
• Wireless communication modules
• Electronic equipment requiring frequency filtering

Procurement Notes

Verify the current product status before procurement, as this specific part number is listed as obsolete. Confirm availability through authorized distributors or secondary market suppliers. Ensure that the 0402 package dimensions and electrical specifications align with the target design requirements. Check for valid replacement components if new production is required.

Selection Notes

Select this component for applications requiring a low-pass filter with a center frequency near 4.242 GHz. Consider the 0.35 dB insertion loss and 3.516 GHz bandwidth when evaluating signal integrity. The 0402 package size dictates the available board real estate. Verify compatibility with existing RF circuit topologies and impedance matching networks.

Part Context

This component belongs to the LPF series of radio frequency filters from KYOCERA AVX. These devices are engineered for high-frequency applications where precise frequency selection and rejection are necessary. The series typically offers various configurations to meet diverse RF system requirements across consumer and industrial electronics.

Replacement Considerations

As the LPF04023600LTT is marked obsolete, identify equivalent low-pass filters from the same manufacturer or competitors. Ensure replacements match the 0402 package, 4.242 GHz center frequency, and similar bandwidth and insertion loss specifications.
