LQM2HPN1R0MJ0L

$0.16

Description：FIXED IND 1UH 1.5A 113 MOHM SMD
Series：LQM2
Mfr：Murata Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:8015252dbe80 Category: Fixed Inductors Brand: Murata Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LQM2HPN1R0MJ0L is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Murata Electronics. Its product description is FIXED IND 1UH 1.5A 113 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for LQM2HPN1R0MJ0L

Description：FIXED IND 1UH 1.5A 113 MOHM SMD
Series：LQM2
Mfr：Murata Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Multilayer
Material - Core：-
Inductance：1 µH
Tolerance：±20%
Current Rating (Amps)：1.5 A
Current - Saturation (Isat)：-
Shielding：Shielded
DC Resistance (DCR)：113mOhm Max
Q @ Freq：-
Frequency - Self Resonant：70MHz
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：1 MHz
Mounting Type：Surface Mount
Package / Case：1008 (2520 Metric)
Supplier Device Package：1008 (2520 Metric)
Size / Dimension：0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max)：0.039" (1.00mm)
Features：-

Fixed Inductors datasheet and documents for LQM2HPN1R0MJ0L

LQM2HPN1R0MJ0L

Fixed Inductors Overview

The Murata LQM2HPN1R0MJ0L is a shielded multilayer power inductor in the 1008 (2520 metric) package. It features a ferrite core with an inductance of 1 uH and a tolerance of 20%. The component has a maximum DC current rating of 2.3 A, a saturation current of 2.3 A, and a maximum DC resistance of 63 mOhms. Operating temperatures range from -40 C to +85 C, with a self-resonant frequency of 50 MHz.

Fixed Inductors Feature Summary

Shielded multilayer construction using ferrite core material
High current handling capability up to 2.3 A
Low DC resistance for efficient power delivery

Fixed Inductors Applications

Power supply circuits
DC-DC converter modules
General power electronics applications

Fixed Inductors Procurement Notes

Verify the specific suffix 'J0' against official documentation to confirm exact electrical tolerances and packaging specifications. Confirm RoHS compliance status through the manufacturer datasheet. Check lifecycle status as some variants may be marked NRND. Ensure the ordering suffix matches the required lead time and availability constraints for production schedules.

Fixed Inductors Selection Notes

Select this component when a 1 uH inductance value is required in a 1008 footprint. Consider the 2.3 A current rating for load requirements. Verify that the 63 mOhms resistance meets thermal design goals. Compare against other LQM series parts if different temperature ranges or higher current densities are needed.

Fixed Inductors Part Context

This part belongs to the Murata LQM series of high-power surface-mount inductors. These components are designed for compact power circuit designs requiring reliable performance. The 1008 package size offers a balance between current capacity and board space efficiency compared to smaller packages.
