LR B6SP-CADB-1-1

LED Indication - Discrete Overview

The LR B6SP-CADB-1-1 is a single-color red power side LED manufactured by ams OSRAM. It features a PLCC-2 surface-mount package with a round, colorless lens measuring 3.4 mm in size. The component emits at a wavelength of 623 nm with a luminous flux of 19.9 lm and an optical intensity of 2.8 cd. Electrical characteristics include a forward current rating of 140 mA and a forward voltage of 2.1 V.

LED Indication - Discrete Feature Summary

• High-power output capability within the Power SideLED series
• Side-emitting configuration for directional illumination
• Surface-mount design compatible with automated assembly processes

LED Indication - Discrete Applications

• Automotive exterior lighting systems
• Industrial signal indicators
• High-brightness general illumination modules

LED Indication - Discrete Procurement Notes

Verify availability status directly with the manufacturer or authorized distributors as lifecycle information is not explicitly detailed in public catalogs. Confirm that the PLCC-2 package dimensions align with PCB footprint requirements prior to ordering. Ensure compliance with RoHS directives if required for specific regional regulations.

LED Indication - Discrete Selection Notes

Select this component when high luminous flux is required from a compact side-emitting form factor. The 140 mA forward current rating supports higher brightness applications compared to standard indicator LEDs. Consider the 623 nm wavelength for visibility requirements where deep red emission is necessary.

LED Indication - Discrete Part Context

This part belongs to the Power SideLED family, designed for applications demanding superior light output in small footprints. It utilizes advanced semiconductor technology to achieve high efficiency within the PLCC-2 package, distinguishing it from lower-power standard SMD LEDs.

LED Indication - Discrete Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer for direct replacements or updated series equivalents.
