LRC20-330M-RC

Fixed Inductors Overview

The LRC20-330M-RC is a surface-mount shielded power inductor manufactured by Allied Components International. It features a rectangular package with two terminals and operates within a temperature range of -40°C to +85°C. The component has a nominal inductance of 33 µH with a tolerance of ±20%. It exhibits a maximum DC resistance of 1.6 Ω, measured at 30% tolerance. The device is rated for a saturation current (Isat) of 1.7 A and an RMS current (Irms) of 1.2 A. It complies with RoHS standards and is designed for general-purpose applications.

Fixed Inductors Feature Summary

• Magnetically shielded construction to minimize electromagnetic interference
• Low profile design suitable for high mounting density
• RoHS compliant manufacturing process

Fixed Inductors Applications

• Power supply circuits
• General purpose filtering
• DC-DC converter modules

Fixed Inductors Procurement Notes

Verify the specific electrical parameters against the official datasheet before integration. Confirm that the operating temperature range and current ratings meet the system requirements. Ensure the surface mount footprint matches the PCB layout. Check for RoHS compliance documentation if required by regulatory standards. Validate the supplier source to ensure authenticity.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with moderate inductance is required for space-constrained designs. Consider the saturation and RMS current limits to prevent performance degradation under load. The low profile facilitates automated assembly processes. Evaluate the DC resistance impact on overall circuit efficiency. Compare with alternative packages if higher current handling is needed.

Fixed Inductors Part Context

This part belongs to the LRC series of low resistance chip inductors from Allied Components International. The series offers various inductance values and current ratings in standardized surface mount packages. These components are designed for use in modern electronic devices requiring reliable magnetic shielding and compact form factors.
