LRHQ20-151K-RC

Fixed Inductors Overview

The LRHQ20-151K-RC is a surface-mount general-purpose inductor manufactured by Allied Components International. It features a ferrite core and is designed for power applications with a nominal inductance of 15 µH and a tolerance of ±10%. The component utilizes high saturation core material to achieve low DC resistance and supports high current ratings based on an inductance drop of less than 10% from the initial value. Electrical measurements are conducted at 1 kHz with no DC current applied.

Fixed Inductors Feature Summary

• High saturation core material utilized for high inductance and low DC resistance
• Surface mount package design suitable for automated assembly
• Non-standard values and tolerances available upon request

Fixed Inductors Applications

• Power supply filtering circuits
• General purpose signal processing
• Electronic equipment requiring compact magnetic components

Fixed Inductors Procurement Notes

Verify that the specific order matches the Allied Components International part number LRHQ20-151K-RC. Confirm compliance with RoHS standards as indicated in official documentation. Ensure the application environment remains within the specified operating temperature range. Check for any specific handling requirements related to surface mount technology during procurement.

Fixed Inductors Selection Notes

Select this component when a 15 µH inductance with ±10% tolerance is required in a surface mount format. Consider the low DC resistance characteristics for efficiency in power applications. Evaluate the saturation current limits against the circuit's maximum load requirements. Verify compatibility with standard PCB footprint dimensions for the LRHQ series.

Fixed Inductors Part Context

This component belongs to the LRHQ series of chip inductors produced by Allied Components International. The series offers various inductance values and tolerances, catering to diverse electronic design needs. The LRHQ20-151K-RC specifically addresses applications requiring reliable performance in a compact surface mount package with ferrite core construction.

Fixed Inductors Replacement Considerations

Cross-reference with other Allied Components International LRHQ series variants if different inductance or tolerance values are needed. Ensure substitute parts maintain compatible physical dimensions and electrical characteristics such as DC resistance and saturation current.
