LT8336JV#PBF

$7.78

Description：IC REG BOOST ADJ 2.5A 16LQFN
Series：-
Mfr：Analog Devices Inc.
Package：Tray

SKU:41846ac737b2 Category: Voltage Regulators - DC DC Switching Regulators Brand: Analog Devices Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC REG BOOST ADJ 2.5A 16LQFN
Series：-
Mfr：Analog Devices Inc.
Package：Tray
Function：Step-Up
Output Configuration：Positive
Topology：Boost
Output Type：Adjustable
Number of Outputs：1
Voltage - Input (Min)：2.7V
Voltage - Input (Max)：40V
Voltage - Output (Min/Fixed)：2.7V
Voltage - Output (Max)：40V
Current - Output：2.5A
Frequency - Switching：300kHz ~ 3MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：16-TFQFN Exposed Pad
Supplier Device Package：16-LQFN (3x3)
Grade：-
Qualification：-

Download product information

LT8336JV#PBF

Overview

The LT8336JV#PBF is a synchronous step-up DC/DC converter manufactured by Analog Devices Inc. It features a 40V, 2.5A internal switch and operates from an input voltage range of 2.7V to 40V. The device generates output voltages between 2.7V and 40V with a maximum output current of 2.5A. It offers a low quiescent current of 300nA and supports programmable switching frequencies from 300kHz to 3MHz. The component functions within a temperature range of -40°C to +125°C and utilizes a surface-mount package.

Feature Summary

Synchronous boost topology with integrated 40V, 2.5A power switch
Ultra-low static current consumption for high efficiency at light loads
Programmable switching frequency allows optimization for size or EMI performance
Silent Switcher architecture minimizes electromagnetic interference radiation

Applications

Battery-powered portable equipment requiring efficient voltage boosting
Industrial control systems operating in harsh thermal environments
Automotive electronics utilizing wide input voltage ranges
Telecommunications infrastructure power management modules

Procurement Notes

Verify the specific suffix designation against official Analog Devices documentation to confirm pinout compatibility and thermal characteristics. Ensure that the procurement channel provides valid traceability records. Confirm RoHS compliance status through the manufacturer's latest certification documents before integration into regulated assemblies.

Selection Notes

Select this component when designing circuits requiring a wide input voltage span up to 40V with moderate current demands. Consider the thermal performance requirements given the operational temperature limits. Evaluate the external component selection for inductors and capacitors to ensure stability across the specified frequency range and load conditions.

Part Context

This part belongs to the LT8336 family of Silent Switcher regulators designed for high-efficiency power conversion. It shares architectural similarities with other members like the LT8337 but differs in voltage and current ratings. The series emphasizes compact design and reduced electromagnetic interference for sensitive electronic applications.
