LTC3875IUH

Description：IC POWER MANAGEMENT
Series：-
Mfr：Analog Devices Inc.
Package：Tube

SKU:191b3bf04bb8 Category: DC DC Switching Controllers Brand: Analog Devices Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LTC3875IUH is listed in the DC DC Switching Controllers range at ChipApex. The manufacturer field lists Analog Devices Inc.. Its product description is IC POWER MANAGEMENT. Review the specifications below when checking this part for your BOM.

DC DC Switching Controllers specifications for LTC3875IUH

Description：IC POWER MANAGEMENT
Series：-
Mfr：Analog Devices Inc.
Package：Tube
Output Type：Transistor Driver
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Number of Outputs：2
Output Phases：2
Voltage - Supply (Vcc/Vdd)：4.5V ~ 38V
Frequency - Switching：250kHz ~ 720kHz
Duty Cycle (Max)：-
Synchronous Rectifier：Yes
Clock Sync：No
Serial Interfaces：-
Control Features：Current Limit, Enable, Frequency Control, Phase Control, Power Good, Soft Start, Tracking
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount
Package / Case：40-WFQFN Exposed Pad
Supplier Device Package：40-QFN (5x5)
Grade：-
Qualification：-

DC DC Switching Controllers datasheet and documents for LTC3875IUH

LTC3875IUH

DC DC Switching Controllers Overview

The LTC3875IUH is a dual-phase synchronous buck controller designed for high-efficiency power conversion. It operates with an input voltage range of 4.5V to 14V and supports output currents up to 120A when paired with appropriate external components. The device features a fixed switching frequency of 400kHz and provides a single non-isolated output, typically configured at 1V. It utilizes DCR current sensing technology to eliminate sense resistors, thereby improving efficiency. The component is housed in a 28-lead QFN package.

DC DC Switching Controllers Feature Summary

Integrates dual-phase synchronous current mode control architecture
Employs very low DCR current sensing capability for enhanced efficiency
Includes on-chip drivers and remote output voltage sensing functionality

DC DC Switching Controllers Applications

High-density point-of-load (POL) converters
Server and workstation power distribution systems
Telecommunications infrastructure equipment
Industrial automation power supplies

DC DC Switching Controllers Procurement Notes

Verify the specific suffix and tape/reel quantity against the manufacturer's latest documentation before ordering. Confirm that the intended application matches the thermal and electrical specifications provided in the official datasheet. Ensure compatibility with the required PCB layout guidelines to maintain performance integrity.

DC DC Switching Controllers Selection Notes

Select this controller for applications requiring high current density and efficient power management without the loss associated with sense resistors. Consider the 400kHz switching frequency for optimal trade-offs between size and efficiency. Ensure the design accommodates the necessary external inductors and capacitors to support the 120A output capability.

DC DC Switching Controllers Part Context

This component belongs to the LTC3875 series of dual-phase controllers from Analog Devices. It is commonly evaluated using demonstration boards such as the DC2055A and DC2142A, which are designed to showcase its performance in 4.5V to 14V input, 1V output configurations. These tools assist in validating the controller's capabilities in real-world scenarios.
