LTC6804HG-1#3ZZPBF

$27.16

Description：IC BATT MON MULTI 1-12C 48SSOP
Series：-
Mfr：Analog Devices Inc.
Package：Tube

SKU:d02a4c1f9cf2 Category: Battery Management Brand: Analog Devices Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC BATT MON MULTI 1-12C 48SSOP
Series：-
Mfr：Analog Devices Inc.
Package：Tube
Function：Battery Monitor
Battery Chemistry：Multi-Chemistry
Number of Cells：1 ~ 12
Fault Protection：Over/Under Voltage
Interface：I2C, SPI
Operating Temperature：-40°C ~ 125°C (TA)
Grade：Automotive
Qualification：-
Mounting Type：Surface Mount
Package / Case：48-FSOP (0.209", 5.30mm Width)
Supplier Device Package：48-SSOP

Download product information

LTC6804HG-1#3ZZPBF

Overview

The LTC6804HG-1#3ZZPBF is a multicell battery stack monitor manufactured by Analog Devices Inc. It operates within a supply voltage range of 11 V to 55 V and provides an output voltage of 5.6 V. The device draws a working supply current of 550 uA and functions reliably across temperatures from -40 C to +125 C. It is housed in an SSOP-48 package designed for surface mount installation.

Feature Summary

Designed for monitoring multiple cells in battery stacks
Supports high-voltage operation up to 55 V
Industrial temperature rating for harsh environments

Applications

Battery management systems
Multicell battery monitoring
Battery protection circuits

Procurement Notes

Verify availability status as the component may be subject to restricted supply or limited distribution channels. Confirm RoHS compliance details through official documentation before procurement. Ensure the specific suffix matches project requirements for package and environmental ratings.

Selection Notes

Select this part for applications requiring direct monitoring of multiple series-connected cells. Verify that the operating voltage range aligns with the system's power supply. Consider the SSOP-48 package constraints during PCB layout design.

Part Context

This component belongs to the LTC6804 series of battery monitors. It is categorized under PMIC - Power Management ICs and specifically Battery Protection products. The manufacturer is Analog Devices Inc., which specializes in signal processing and power management solutions.
