LTL-4232

LED Indication - Discrete Overview

The LTL-4232 is a single-color green LED lamp from the Lite-On LTL series. It utilizes a T-1 (3mm) radial through-hole package with two pins and an orange transparent lens. The device emits light at a peak wavelength of 565nm with a viewing angle of 60 degrees. Key electrical parameters include a maximum forward current of 30mA, a typical forward voltage of 2.2V, and a nominal luminous intensity of 40mcd. It operates within a temperature range of -55°C to +100°C.

LED Indication - Discrete Feature Summary

• Provides high-efficiency green illumination suitable for indicator applications
• Features a standard T-1 3mm radial lead frame for easy mounting
• Includes a transparent lens design for clear visibility

LED Indication - Discrete Applications

• Panel status indicators
• Power supply visual feedback
• Electronic equipment signaling

LED Indication - Discrete Procurement Notes

Verify the specific suffix variant required, as the base model may correspond to different packaging options such as bulk or tape and reel. Confirm RoHS compliance status and check for any obsolete status updates directly with the manufacturer before finalizing procurement plans.

LED Indication - Discrete Selection Notes

Select this component when a standard 3mm green indicator is needed for general-purpose electronics. Ensure the circuit design accommodates the 2.2V forward voltage drop and limits current to the specified 30mA maximum rating to maintain reliability and longevity.

LED Indication - Discrete Part Context

This part belongs to the LTL series of solid-state LED lamps manufactured by Lite-On. The series includes various colors and intensities, with the LTL-4232 specifically designated for green light emission. It represents a standard discrete optoelectronic component used in industrial and consumer hardware.

LED Indication - Discrete Replacement Considerations

Compatible substitutes within the same family include the LTL-4231N and LTL-4236N. Verify that alternative parts match the 3mm T-1 package dimensions and electrical characteristics before integration.
