LTM9002CV-LA#PBF

Overview

The LTM9002CV-LA#PBF is a dual-channel intermediate frequency (IF) to baseband receiver subsystem manufactured by Analog Devices Inc. It integrates a high-speed 14-bit analog-to-digital converter, matching networks, anti-aliasing filters, and two low-noise amplifiers within a single system-in-package. The device operates with a parallel CMOS data output interface and supports an operating temperature range from 0°C to +70°C. Packaged in a 108-lead LGA footprint measuring 15mm by 11.25mm, it is designed for direct sampling of RF signals.

Feature Summary

• Integrates dual-channel 14-bit ADCs with low-noise amplifiers and anti-aliasing filters
• Supports direct IF-to-baseband conversion without external mixers
• Utilizes system-level packaging for compact board space reduction

Applications

• Wireless infrastructure base stations
• Software-defined radio systems
• Direct RF sampling receivers

Procurement Notes

This component is classified as End of Life and scheduled for obsolescence by the manufacturer. Availability is strictly limited to existing stock or factory special orders. Verify current lifecycle status and lead times with authorized distributors before design finalization, as replacement sourcing may require significant validation efforts.

Selection Notes

Engineers should evaluate this part primarily for legacy system maintenance or specific high-performance IF sampling requirements where its integrated architecture reduces bill-of-materials complexity. Due to its end-of-life status, alternative solutions with longer availability windows are recommended for new designs requiring long-term supply chain stability.

Part Context

The LTM9002 belongs to Analog Devices' family of integrated receiver subsystems designed to simplify RF front-end architectures. By combining ADCs, LNAs, and filtering in a single package, it targets applications demanding high linearity and low noise figure while minimizing external component count and PCB area compared to discrete implementations.
