Product Detailed Parameters
- Description：IC MOTOR DRIVER 2.5V-5.5V 16VCT
- Series：-
- Mfr：onsemi
- Package：Tube,Tube
- Motor Type - Stepper：-
- Motor Type - AC, DC：Brushed DC
- Function：Driver - Fully Integrated, Control and Power Stage
- Output Configuration：Half Bridge (2)
- Interface：Parallel
- Technology：Bi-CMOS
- Step Resolution：-
- Applications：General Purpose
- Current - Output：500mA
- Voltage - Supply：2.5V ~ 5.5V
- Voltage - Load：2.5V ~ 5.5V
- Operating Temperature：-30°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Package / Case：16-WFQFN
- Supplier Device Package：16-VCT (2.6x2.6)
- Grade：-
Download product information
Overview
The LV8075LP-E is a single-channel forward/reverse motor driver manufactured by onsemi, designed for low-voltage applications. It operates within a supply voltage range of 2.5 V to 6 V and delivers an output current of up to 400 mA. The device features a constant current control mechanism and utilizes a 16-pin VCT package with dimensions of 2.6 mm x 2.6 mm. It supports surface-mount installation and functions at maximum operating temperatures of +85°C. The component is categorized under Motor Controllers and Drivers, specifically targeting stepper motor control applications.
Feature Summary
- Provides single-channel forward and reverse motor control functionality
- Utilizes constant current regulation for precise motor driving
- Designed for low-power operation with minimal standby current consumption
Applications
- Stepper motor control in compact electronic devices
- Motion control systems requiring low voltage operation
- Small appliance drive circuits
Procurement Notes
Verify the specific suffix and marking code against the official datasheet to ensure authenticity, as counterfeit components may exist. Confirm that the package type matches the required 16-VCT specification. Check for any end-of-life notices or obsolescence status from the manufacturer before finalizing procurement plans.
Selection Notes
Select this component when a single-channel bidirectional driver is required for small stepper motors. Ensure the system voltage remains within the 2.5 V to 6 V operational range. Consider the thermal performance and PCB layout requirements associated with the small VCT package size for adequate heat dissipation.
Part Context
This part belongs to the LV8080LP series family from onsemi, which focuses on low-voltage motor control solutions. It shares design similarities with other members like the LV8080LP-E but offers single-channel capability instead of dual-channel outputs. The series targets cost-sensitive and space-constrained motion control applications.
Replacement Considerations
Direct substitutes include the LV8075LP without the E suffix if environmental compliance differences are acceptable. Cross-reference with the LV8080LP-E if dual-channel functionality can be accommodated by the design.
