LV8136V-MPB-H

Overview

The LV8136V-MPB-H is a three-phase brushless DC motor pre-driver IC manufactured by onsemi. It operates within a supply voltage range of 9.5V to 16.5V and features an SSOP-30 package. The device provides an output current capability of 150mA, designed for industrial temperature grade applications. This component functions as a parallel interface driver intended to control external power stages for BLDC motors.

Feature Summary

• Supports three-phase brushless DC motor control via parallel interface
• Operates with supply voltages between 9.5V and 16.5V
• Designed for industrial temperature grade environments

Applications

• Three-phase brushless DC motor systems
• Industrial motor control applications
• Pre-driver stages for BLDC motor drives

Procurement Notes

Verify the exact suffix and package type when ordering, as variations exist within the LV8136V family. Confirm that the specific part number matches the required interface and voltage specifications for your design. Check manufacturer documentation for any recent product change notices or certification updates before finalizing procurement.

Selection Notes

Select this component when a dedicated pre-driver for three-phase BLDC motors is required. Ensure the system voltage falls within the 9.5V to 16.5V operating range. Consider the 150mA output current capability relative to the gate drive requirements of the external MOSFETs or IGBTs in the power stage.

Part Context

This part belongs to the LV8136V series of motor drivers from onsemi. It is distinct from evaluation boards like the LV8136VGEVB, which are development tools rather than production components. The MPB-H suffix indicates a specific package and tape-and-reel configuration suitable for automated assembly.

Replacement Considerations

Direct substitutes may include other onsemi three-phase BLDC pre-drivers with similar voltage ranges and pinouts. Verify compatibility with existing PCB footprints and control logic levels before replacing.
