LV8804V-TLM-H

Overview

The LV8804V-TLM-H is a fully integrated brushless DC (BLDC) motor driver manufactured by onsemi. It combines a control and power stage in a single package, designed for high-performance applications. The device operates within a supply voltage range of 6 V to 15 V and utilizes Bi-CMOS technology. It features a 36-pin SSOPJ package with dimensions of approximately 5.2 x 4.4 x 1.3 mm. The component supports a maximum output current of 1.2 A and includes built-in protection mechanisms such as overcurrent and thermal shutdown.

Feature Summary

• Fully integrated control and power stage in a single package
• Built-in overcurrent and thermal shutdown protection
• Designed for high-performance BLDC motor applications

Applications

• Brushless DC fan motors
• Small appliance motor control
• Industrial automation actuators

Procurement Notes

Verify the specific suffix 'TLM-H' against official onsemi documentation to confirm package type and tape/reel specifications. Confirm RoHS compliance status through the manufacturer's latest datasheet or certification documents. Check for End-of-Life (EOL) notices or Last-Time-Buy dates directly from onsemi channels before finalizing procurement plans.

Selection Notes

Select this component when a compact, integrated solution for BLDC motor control is required. Ensure the application voltage stays within the 6 V to 15 V range. Verify that the 1.2 A output current capability meets the motor load requirements. Consider the 36-pin SSOPJ package constraints for PCB layout and thermal management during the design phase.

Part Context

This part belongs to onsemi's family of motor drivers, specifically targeting BLDC applications. It integrates logic and power stages to simplify system design. The device is distinct from other series like LV8729V due to its specific pinout and current handling capabilities tailored for three-phase motor control.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult onsemi technical support for direct replacements or cross-reference options based on specific electrical and mechanical requirements.
