LVA-273PN+

Overview

The Mini-Circuits LVA-273PN+ is a wideband distributed MMIC amplifier operating from 0.01 to 26.5 GHz. Fabricated on GaAs HBT technology, it delivers 18 dB gain with ultra-low phase noise and high dynamic range. Key electrical parameters include +18 dBm P1dB, +28 dBm OIP3, and a noise figure of 3.7 dB. The device features 50 Ohm impedance and is housed in a compact 4x4 mm QFN package.

Feature Summary

• Ultra-low phase noise performance for signal integrity
• High dynamic range across the entire frequency band
• Distributed amplifier architecture for wide bandwidth

Applications

• 5G infrastructure systems
• Radar applications
• Test and measurement equipment

Procurement Notes

Verify the specific datasheet version when sourcing, as Mini-Circuits may update component specifications over time. Ensure compatibility with standard SMT reflow processes for the QFN package. Confirm that the supply chain source provides genuine components with traceable manufacturing origins to maintain signal quality standards.

Selection Notes

Select this component when designing circuits requiring broad bandwidth coverage up to 26.5 GHz with minimal phase noise degradation. It is suitable for linear amplification needs where high output power handling is critical. Consider the thermal management requirements associated with the QFN package layout during PCB design.

Part Context

This part belongs to Mini-Circuits' portfolio of RF and microwave signal processing devices. The manufacturer specializes in components for wireless communications and industrial control. The LVA series typically targets high-frequency applications requiring reliable performance in demanding environments.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
