LW M67C-T2U2-LKML-1-20-R18-Z-VIS

LED Indication - Discrete Overview

The LW M67C-T2U2-LKML-1-20-R18-Z-VIS is a single-color visible light surface-mount LED from the Mini TOPLED series by ams OSRAM. It features an orange emission with a clear, non-diffused lens. The component utilizes a compact SMD package designed for automated assembly processes. Key electrical parameters include a forward voltage of approximately 2.0 V and a test current of 20 mA. The device is rated for operation within a temperature range of -40°C to +100°C and complies with RoHS standards.

LED Indication - Discrete Feature Summary

• Miniature surface-mount form factor suitable for space-constrained designs
• Orange visible light emission with a clear optical lens
• Automotive-grade reliability qualification via AEC-Q100 standard
• High thermal stability supporting extended operating temperatures

LED Indication - Discrete Applications

• Status indication in automotive electronic control units
• Instrument cluster illumination
• Interior vehicle lighting systems
• General-purpose indicator lights in industrial equipment

LED Indication - Discrete Procurement Notes

Verify component authenticity through authorized distribution channels. Confirm that the specific ordering suffix matches the required optical and electrical specifications. Ensure storage conditions adhere to moisture sensitivity levels to prevent package damage during soldering. Cross-reference the latest datasheet for any updates regarding compliance or mechanical dimensions before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component when a small footprint is critical for the PCB layout. Consider the specific orange wavelength requirements for visibility needs. Evaluate the thermal management capabilities of the target application against the maximum operating temperature limits. Ensure the driving circuit provides stable current regulation to maintain consistent luminous intensity over the device's lifespan.

LED Indication - Discrete Part Context

This part belongs to the Mini TOPLED family, which focuses on reducing component size while maintaining performance. It serves as a specialized optoelectronic solution for modern electronics requiring high-density mounting. The series is engineered to meet stringent automotive quality standards, ensuring long-term reliability in demanding environments compared to standard commercial-grade LEDs.

LED Indication - Discrete Replacement Considerations

Public sources indicate this specific part number is obsolete. Available substitutes include other variants within the Mini TOPLED series such as LW M67C-T2U2-LKML-1-20-R18-Z-XX. Verify mechanical compatibility and optical characteristics when selecting alternative components from the manufacturer's current portfolio.
