LW P473-R1R2-FKPL-1-10-R18-Z

LED Indication - Discrete Overview

The LW P473-R1R2-FKPL-1-10-R18-Z is a surface-mount white LED from the Mini TOPLED series by ams OSRAM. It features a rectangular, diffused lens and operates with a forward current of 20mA. The device provides a wide viewing angle of 120 degrees. Typical optical performance includes a luminous flux range of 150 to 480 millilumens and an intensity range of 45 to 180 millicandela. The forward voltage is specified at 3.4V. The component measures 1.5 x 2.1 x 1.4mm and utilizes a two-pin configuration for standard SMT assembly processes.

LED Indication - Discrete Feature Summary

• Miniature surface-mount package designed for space-constrained applications
• Wide 120-degree viewing angle for broad light distribution
• Diffused rectangular lens for uniform illumination output

LED Indication - Discrete Applications

• Indicator lighting in consumer electronics
• Backlighting for small displays
• Status indication in portable devices

LED Indication - Discrete Procurement Notes

Verify the specific binning codes and wavelength coordinates required for your application against the manufacturer's latest datasheet. Confirm that the ordering suffix matches the exact optical and electrical specifications needed. Ensure compatibility with standard reflow soldering profiles recommended for Mini TOPLED components to maintain reliability.

LED Indication - Discrete Selection Notes

Select this component when a compact footprint and wide beam angle are prioritized over high-intensity output. Consider the 3.4V forward voltage drop for power budget calculations. Evaluate the 150-480 mlm flux range to ensure sufficient brightness for the intended visual application without excessive power consumption.

LED Indication - Discrete Part Context

This part belongs to the Mini TOPLED family, which focuses on miniaturization while maintaining reliable LED performance. It serves as a solution for modern electronic designs requiring small form factors. The series supports various colors and intensities tailored for different industrial and consumer needs.

LED Indication - Discrete Replacement Considerations

Direct substitutes within the same Mini TOPLED series may be available with different color temperatures or intensity bins. Verify pinout compatibility and thermal characteristics before swapping. Consult official cross-reference guides for equivalent parts with matching mechanical dimensions.
