LWA10-24-15-A-CEC

LWA10-24-15-A-CEC is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Polytron. Its product description is DC DC CONVERTER +/-15V 10W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for LWA10-24-15-A-CEC

• Description：DC DC CONVERTER +/-15V 10W
• Series：LWA10 (10W)
• Mfr：Polytron
• Package：Tray
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-15V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：333mA, 333mA
• Power (Watts)：10 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：81%
• Mounting Type：Through Hole
• Package / Case：5-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE, cURus, UL
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for LWA10-24-15-A-CEC
