LX20 H

Power Line Filter Modules Overview

The LX20 H is a single-phase EMC/EMI line filter manufactured by Astrodyne TDI. It features a two-stage configuration designed to suppress electromagnetic interference in electrical circuits. The unit is rated for 20 A current and operates at 250 VAC on 50/60 Hz systems. It utilizes quick connect terminals for installation and is housed in a chassis-mount enclosure.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Quick connect terminal interface for simplified integration
• Chassis-mount design for secure physical installation

Power Line Filter Modules Applications

• General purpose electronic equipment requiring EMI suppression
• Single-phase power line protection
• Industrial control systems

Power Line Filter Modules Procurement Notes

Verify the specific part number suffix against official Astrodyne TDI documentation to confirm exact ratings and terminal configurations. Ensure the selected variant matches the required voltage, current, and mounting specifications for the target application before procurement.

Power Line Filter Modules Selection Notes

Select this component based on its 20 A rating and 250 VAC compatibility for single-phase applications. Confirm that the chassis-mount form factor and quick-connect terminals align with the system's mechanical and electrical interface requirements.

Power Line Filter Modules Part Context

The LX20 H belongs to the LX20 Power Line Filter Modules series from Astrodyne TDI. This series provides EMI/EMC solutions for demanding environments. The manufacturer specializes in power supplies and filter technologies for global industrial and commercial markets.

Power Line Filter Modules Replacement Considerations

Consult official Astrodyne TDI substitution guides for verified equivalents. Cross-reference technical parameters such as current rating, voltage, and stage configuration when evaluating alternative components.
