M-F-8.192M-15-3030-2070-60

Crystals Overview

The M-F-8.192M-15-3030-2070-60 is a quartz crystal resonator manufactured by CEC Xtal, designed for precision timing applications. It operates at a nominal frequency of 8.192 MHz with a frequency tolerance of ±30 ppm. The component features a load capacitance of 15 pF and utilizes a 2-SMD, No Lead package configuration. It supports an operating temperature range from -20°C to +70°C, ensuring stable performance in standard electronic environments.

Crystals Feature Summary

• Provides precise frequency stability with ±30 ppm tolerance across the specified temperature range
• Utilizes a compact 2-SMD, No Lead package design suitable for surface-mount assembly
• Operates with a 15 pF load capacitance for standard circuit integration

Crystals Applications

• Microcontroller clock generation circuits
• Communication interface timing synchronization
• Digital signal processing systems requiring stable reference frequencies

Crystals Procurement Notes

Verify that the specific suffix codes align with the required load capacitance and tolerance specifications for your design. Confirm the operating temperature range meets environmental requirements. Ensure compatibility with surface-mount reflow soldering processes. Check for RoHS compliance status if restricted substances are a concern. Validate pinout and footprint dimensions against PCB layout constraints.

Crystals Selection Notes

Select this component when a stable 8.192 MHz reference is needed with moderate frequency accuracy. Consider the ±30 ppm tolerance relative to system jitter requirements. Evaluate the 2-SMD form factor for space-constrained designs. Compare the -20°C to +70°C range against ambient conditions. Assess the 15 pF load capacitance against existing oscillator circuit parameters.

Crystals Part Context

This part belongs to the CEC Xtal crystal resonator family, which includes various quartz-based timing devices. CEC Xtal specializes in manufacturing quartz crystals and oscillators for consumer electronics and industrial applications. This specific model represents a standard through-hole or surface-mount compatible crystal used for general-purpose clocking.

Crystals Replacement Considerations

Direct substitutes must match the 8.192 MHz frequency, ±30 ppm tolerance, 15 pF load capacitance, and 2-SMD package. Verify equivalent thermal characteristics and electrical parameters before substitution.
