M15733/61-0001

Overview

The M15733/61-0001 is an EMI feedthrough filter manufactured by Tusonix, a subsidiary of CTS Electronic Components. It belongs to the 4204 series and functions as an UNF-2A EMI Pi Filter. The component features a capacitance of 0.01 µF (10 nF) and a voltage rating of 100 V at 125°C. It utilizes a chassis mount configuration with UNF-2A threading. The product is classified under electromagnetic interference filters and is designed for high-performance noise suppression in electronic systems.

Feature Summary

• Provides effective electromagnetic interference suppression through integrated pi-filter topology
• Features robust chassis mounting capability utilizing UNF-2A threaded interface
• Designed for stable operation within specified thermal operating ranges

Applications

• Chassis-mounted electronic equipment requiring EMI mitigation
• Power supply input filtering applications
• Signal line noise suppression in sensitive electronic assemblies

Procurement Notes

Verify the manufacturer designation as Tusonix, a subsidiary of CTS Electronic Components, against official documentation. Confirm the specific capacitance value of 0.01 µF and the 100 V rating at 125°C are consistent with the project requirements. Ensure the UNF-2A thread size matches the mechanical installation constraints. Cross-reference the M15733/61-0001 part number with the manufacturer's current catalog to confirm availability and any potential obsolescence notices before finalizing procurement.

Selection Notes

Select this component when a pi-filter configuration is required for chassis-mounted EMI suppression. The UNF-2A thread standard dictates the mechanical interface compatibility. Consider the 0.01 µF capacitance and 100 V rating to ensure adequate filtering performance for the target frequency spectrum and voltage levels. Verify that the bulk packaging format aligns with the assembly process capabilities.

Part Context

This component is part of the broader M15733 military-style connector and filter family produced by Tusonix/CTS. It serves as a specialized passive component for noise control rather than a signal interconnect device. The 4204 series designation indicates its specific internal circuit topology and physical form factor within the manufacturer's portfolio of feedthrough capacitors and filters.

Replacement Considerations

Consult the manufacturer's cross-reference tools for parametrically similar parts. Potential substitutes must match the 0.01 µF capacitance, 100 V rating, and UNF-2A mechanical threading. Verify that alternative components maintain the same pi-filter architecture to ensure equivalent EMI suppression characteristics.
