M15733/61-0004

Overview

The M15733/61-0004 is an EMI feedthrough filter belonging to the Tusonix 4206 series. It features a capacitance of 2000 pF and a voltage rating of 500 V at 125°C. The component utilizes a UNF-2A thread size for chassis mounting. It is classified as an EMI Pi Filter designed for high-frequency noise suppression in electronic systems.

Feature Summary

• Provides electromagnetic interference attenuation through integrated LC (Pi) filtering topology
• Designed for direct chassis mounting using standardized threaded interfaces
• Capable of handling specified voltage ratings under elevated temperature conditions

Applications

• Chassis-mounted power line filtering
• Electronic equipment requiring EMI suppression
• Signal integrity protection in sensitive circuits

Procurement Notes

Verify the manufacturer designation, specifically Tusonix or CTS Electronic Components, against official documentation. Confirm the exact capacitance value of 2000 pF and the 500 V rating are required for your specific application environment. Ensure the UNF-2A thread specification matches your panel cutout requirements before finalizing procurement decisions.

Selection Notes

Select this component when a 2000 pF capacitance and 500 V rating are necessary for EMI mitigation. The UNF-2A thread size dictates the mechanical integration method. Consider the operating temperature range up to 125°C to ensure reliability within your system's thermal profile and electrical load constraints.

Part Context

This part is part of the broader 4206 series of EMI feedthrough filters manufactured by Tusonix, a subsidiary of CTS. These components are engineered for robust performance in demanding environments, offering reliable signal conditioning and noise reduction capabilities for various industrial and commercial electronic applications.

Replacement Considerations

M15733/61-0004 serves as the military-style part number equivalent for the commercial part number 4206-501. When sourcing replacements, verify that the substitute maintains the identical 2000 pF capacitance, 500 V rating, and UNF-2A threading specifications to ensure mechanical and electrical compatibility.
