M15733/61-0005

Overview

The M15733/61-0005 is an EMI feedthrough filter manufactured by Tusonix, a subsidiary of CTS Electronic Components. It belongs to the MIL-DTL-15733 series and utilizes a Pi-filter circuit topology. The component features a capacitance of 1500 pF and is designed for chassis mounting applications.

Feature Summary

• Provides electromagnetic interference suppression through LC (Pi) filtering architecture
• Designed for direct chassis mounting installation

Applications

• Chassis-mounted electronic equipment requiring EMI mitigation
• Military and aerospace systems adhering to MIL-DTL-15733 standards
• Power supply input/output filtering in sensitive instrumentation

Procurement Notes

Verify the manufacturer designation as Tusonix, a subsidiary of CTS Electronic Components, against the specific part number M15733/61-0005. Confirm the capacitance value of 1500 pF and the Pi-filter configuration. Ensure the package type matches the required chassis mounting specifications for your application.

Selection Notes

Select this component when a 1500 pF capacitance value is required for EMI filtering within MIL-DTL-15733 compliant systems. Consider the Pi-filter topology for superior attenuation characteristics compared to simple feedthrough capacitors. Verify that the chassis mounting style aligns with the mechanical constraints of the enclosure design.

Part Context

This component is part of the broader MIL-DTL-15733 family of feedthrough filters produced by Tusonix/CTS. These components are standardized for high-reliability applications, offering consistent performance across various capacitance values and voltage ratings within the same mechanical form factor.

Replacement Considerations

The part number 4203-502 is identified as a cross-reference or substitute for M15733/61-0005. Verify electrical compatibility before substitution.
