M15733/61-0006

Overview

The M15733/61-0006 is an EMI feedthrough filter manufactured by Tusonix, a subsidiary of CTS Electronic Components. It belongs to the MIL-DTL-15733 series and utilizes a Pi filter circuit topology. The component features a capacitance of 1500 pF and a voltage rating of 200 V at 125°C. It supports a maximum DC current of 10 A and operates within a temperature range of 0°C to +125°C. The housing uses an UNF-2A thread size.

Feature Summary

• Provides electromagnetic interference suppression through integrated LC (Pi) filtering architecture
• Designed for chassis mounting applications requiring high reliability
• Capable of handling significant DC current loads while maintaining signal integrity

Applications

• Military and aerospace electronic systems
• Chassis-mounted power distribution units
• High-reliability communication equipment

Procurement Notes

Verify the specific suffix against the manufacturer's datasheet to ensure correct capacitance and voltage ratings. Confirm thread compatibility with existing panel cutouts. Check RoHS compliance status as indicated in official documentation. Ensure ordering quantities align with factory packaging requirements.

Selection Notes

Select this component when a 1500 pF capacitance and 200 V rating are required for EMI suppression. Consider the UNF-2A thread size for mechanical integration. Evaluate the 10 A current capacity against system load requirements. Compare thermal performance specifications against operational environment limits.

Part Context

This part is part of the MIL-DTL-15733 family of feedthrough capacitors. Tusonix produces these components for defense and industrial sectors. The series offers various capacitance values and thread sizes. This specific model represents a standard configuration within the product line.

Replacement Considerations

Cross-reference tools indicate the 4203-501 as a parametrically similar substitute. Verify electrical parameters and mechanical dimensions before substitution. Ensure the alternative meets all military specification requirements.
